My own fan light, the switch is always sizzling, the light is flashing or not on, the fan is running. After my own maintenance, the switch controls the power supply and lights, and the remote control controls the fan, and the results are satisfactory.

Fan lamp manufacturers

The lights in my house have only one switch and a remote control. The remote control can control the lights and fans. The steps are as follows

One, determine whether the light is good? First cut off the power supply, remove the cover at the receiver of the fan light, and take out the receiver. Then connect the main live wire and neutral wire to the live wire and neutral wire of the fan respectively. The ground wire doesn't go through the receiver, so don't worry about it. After connecting, turn on the switch, can you confirm whether the light is in good condition? The lights in my house, after wiring in this way, the lights will be on, indicating that the lights are good.

Two: first cut off the power supply, disconnect the live wire and neutral wire of the connected lamp, and then connect the main live wire, neutral wire and the incoming live wire and neutral wire of the receiver respectively. Use an electric pen to test the live status of the receiver outlet. There are three wires coming out, namely the light wire, the fan wire, and the public neutral wire. Take a look, do the two live wires have power? In my house, the light wire is not charged (causing the light not to light up, only 36V was measured with a multimeter, so the light would not light up), and the fan fire wire is electric. It means that the receiver is broken. Because the lights are good (tested), so is the fan (the remote can be controlled).

Three: Processing method: I connect the live wire of the lamp, the incoming live wire of the receiver and the main live wire together, the live wire of the fan is connected to the live wire of the receiver, and the incoming neutral wire of the receiver and the fan and lamp The common neutrals are tied together.

In this way, the live wire of the lamp is directly connected to the main live wire, and the neutral wire is also connected to the main neutral wire without passing through the receiver. The live wire from the fan goes through the receiver. The remote control cannot control the lights, only the fans.

Since the fan lights in my house are mounted on the dining table, this result is acceptable. Of course, those who pursue perfection will directly change the receiver and remote control. If you change the receiver yourself, it is also very simple, because there are two incoming wires (live wire and neutral wire) and three outgoing wires (fan live wire, lamp live wire and neutral wire), just connect them separately. I attached a picture for your reference.

4. The black wire on the right side of the receiver is the incoming live wire, which is connected to the green main live wire, and the dark blue wire is the live wire of the lamp. These three wires are connected together. The light blue main neutral line and two white lines (one is the incoming neutral line of the receiver, and the other is the common neutral line of the lamp and fan). The black line on the left is the connection between the live line of the receiver and the live line of the fan.

Through the above introduction, I believe that everyone has a certain understanding of fan lamp self-service maintenance. Fan lamp manufacturer Magic Electric Co., Ltd. is a professional team integrating design, research and development, production and marketing. Its products include decorative ceiling fans, lighting, home appliances and hardware accessories processing. Since its establishment, it has been adhering to the original intention of "making the world full of magic", constantly introducing innovative technology and design and development, creating strong technical force, improving the quality of employees, and strictly controlling the quality of products. People from all walks of life are welcome to consult and understand.
